How much should a switchboard upgrade cost?
We don't publish a price for switchboard upgrades in Berwick yet, because we don't have enough real local quotes to give an honest range. The cost depends mostly on how many circuits the board supplies and how much work sits around the board itself, and an electrician can only price it after seeing the board.
- The number of circuits, and whether each one gets its own RCBO or circuits share a safety switch
- Whether the meter box or the enclosure needs replacing too
- Single-phase or three-phase supply
- Extra capacity for an EV charger, solar or a battery
- Faults found when the circuits are tested, which need fixing before the board is switched back on
- Access, for example a board set into a wall that needs patching afterwards
Ask for an itemised quote, so you can compare two electricians on the same scope of work.
Should I upgrade my switchboard?
Have the board looked at if it still has ceramic fuses, has no safety switch, trips often, or has no room for the circuits a new EV charger, solar system or battery would need. Age alone doesn't settle it: an electrician should inspect the board before recommending a full replacement.
- Ceramic (rewireable) fuses instead of circuit breakers
- No safety switch, or safety switches on only some circuits
- A safety switch or circuit breaker that keeps tripping
- Sparks, scorch marks or a burning smell around the board
- No spare space for new circuits
Energy Safe Victoria lists old switchboards, particularly ones without a safety switch, among the signs that a home's wiring may be faulty.
Safety switch (RCD) installation
A safety switch, or residual current device (RCD), monitors the electricity flowing through a circuit and cuts the power within milliseconds when it detects a problem that puts people at risk. Safety switches work alongside circuit breakers and fuses rather than replacing them. They are usually added as part of a switchboard upgrade, although a board that already has circuit breakers may have room to add them.
If a safety switch trips again straight after you reset it, stop resetting it and have an electrician find the fault on that circuit. Energy Safe Victoria recommends pressing the test button on each safety switch every three months; if the power doesn't go off on that circuit, the switch may have failed.
Rental properties in Victoria must have a switchboard with circuit breakers and safety switches under the rental minimum standards, which began on 29 March 2023. Consumer Affairs Victoria notes that an older fuse board may have to be replaced entirely to meet the standard.
Sources: Energy Safe Victoria: Test. Reset. Protect.; Energy Safe Victoria: Household wiring; Consumer Affairs Victoria: Rental minimum standards
How long does it take to upgrade a switchboard?
Ask the electrician for a time for your job, because it depends on the number of circuits, any meter box work and whether testing turns up faults. The power to the house is off while the board is changed over, so plan for the fridge, any medical equipment and anyone working from home.
The Licensed Electrical Inspector's check of the new board is a separate step that your contractor arranges.
What should you receive after a switchboard upgrade?
You should have an itemised quote before the work starts and a Certificate of Electrical Safety when it is finished. The contractor must give you a copy of the certificate, and switchboard and meter box work must also be inspected by a Licensed Electrical Inspector.
- An itemised quote that lists the board, the safety switches and any meter box work
- Every circuit labelled on the new board
- Your copy of the Certificate of Electrical Safety
- Confirmation that the inspection has been arranged or done
You can check an electrician's licence or a contractor's registration on Energy Safe Victoria's public register before you agree to a quote.
Sources: Energy Safe Victoria: Certificates of Electrical Safety; Energy Safe Victoria: Search a public register
